CadModelAnalysis

Subsea Oil & Gas

Offshore Containers DNV 2.7.3

Analysis & Report for DNV certification.
Load cases :
Lifting 2 Pt & 4 Pt,Test case
Installation
Impact
Operational Load
Drop test
Padeye Design

Subsea Field Structures

Analysis & Report as per DNV 2.7.3 standard
Subsea distribution unit - Hydraulic, Optical & Termination head
Lifting, installtion & Impact loadings
Drop test
Fasterner, weld, Padeye & Mudmat calculation

Pipeline connector

Thermo-mechanical analysis of pipeline connections
Transient Thermal analysis to obtain thermal profile due to variable temperature fluid flow
Temperature, variable pressure and forces are applied as Load
Stress & Fatigue analysis as per ASME Sec 8, Div 2
Determination of Plastic strain & 20 years fatigue life

A frame

Fastener & weld joint strength calculations
1 D A Frame design. Variable operating loads are applied to derive worst reaction loads on Fasteners / Welds. Hand calculations to determine strength of joints.

Electrical & Metering Products

Electrical Meters

Analysis of electrical meter
Thermomechanical analysis:Current & Voltage analysis to evaluate heat generation & current density
Strength analysis: Deformation of plastic & metal parts
Vibration & shock test analysis
Drop test, impact test & high energy arc blast test
Magnetic field analysis: Field around CT and Relay due to magnet & shield
Optical analysis: Selection of lightguide & illuminance under sunlight

Circuit breakers & Switches

Analysis of Circuit breakers & Switches
Current Flow & current density analysis
Temperature rise analysis
Drop test & strength analysis
Arc Flash & spark analysis

Household appliance

Thermal, Structural & fluid circulation analysis
Thermal analysis to optimize design & reduce energy losses
Structural analysis to evaluate strength, vibrations & fatigue behaviour
Drop test analysis

Impellers & Mixing chambers

Centrifugal Compressor

Design & CFD & FEA Analysis
Initial Blade design in Vista ccd & Bladegen
Initial Flow analysis in Ansys CFX
Strength verification in Ansys Mechanical

Sugarcane fluid mixing in chamber

CFD mixing of fluid in chamber
Thermal analysis of Charger (Heat rise due to PCB & copper plates)
Solar heating effects on chargers
Drop test & strength analysis
IK test & strength of Locks

Electronics & Technology Products

PCBA Analysis

Analysis PCBA & ICs
Effect of copper traces, layers & ICs on temperature profile of PCB
Component/IC placements & air circulation around PCB
Vibration & strength analysis

EV Chargers

Thermal & strength analysis of EV chargers
Thermal analysis of Charger (Heat rise due to PCB & copper plates)
Solar heating effects on chargers
Drop test & strength analysis
IK test & strength of Locks

Payment Gateway devices

Thermal & strength analysis
Thermal analysis due to heat rise due to PCB & copper plates
Drop test & strength analysis
IK test & Impact test

-->
